型 号 Model： |
FT9025M |
|
产品名称 Product Name: |
6V 8.5kg.cm数码180度铝壳金属齿轮空芯杯舵机 |
| 存储温度 Storage Temperature Range | -30℃～80℃ |
| 运行温度 Operating Temperature Range: | -20℃～60℃ |
|
尺寸 Size: |
A：36mm B：15mm C: 29.2mm |
|
重量 Weight: |
35.2± 1g |
| 齿轮类型 Gear type: |
Metal Gear |
| 机构极限角度 Limit angle: |
NO limit |
| 轴承 Bearing: | 滚珠轴承 Ball bearings |
| 出力轴 Horn gear spline: |
25T/5.9mm |
| 外壳 Case: | Alumi num |
| 舵机线 Connector wire: | 25CM |
| 马达 Motor: |
Coreless Motor |
|
工作电压Operating Voltage Range: |
4.8-6V |
| 静态电流Idle current (atstopped) |
6MA@6V |
|
空载速度 No load speed: |
0.133sec/60°@6V |
| 空载电流 Runnig current(at no load) : | 200mA@6V |
|
堵转扭矩 Peak stall torque: |
8.5kg.cm@6V |
|
额定扭矩 Rated torque: |
2.8kg.cm@6V |
| 堵转电流 Stall current: | 1.4A@6V |
| 控制信号Command si gnal | Pulse width modification |
| 放大器类型Amplifier type | Digital comparator |
| 脉冲宽度范围Pulse width range | 500~2500 μ sec |
| 中立位置Stop position | 1500 μ sec |
| 旋转角度Running degree |
180°(at 500→2500μsec) |
| 死区宽度Dead band width | ≤4 μ sec |
| 旋转方向Rotating direction | 逆时针 Counterclockwi se (在1500→2000 μ sec) |
| 详细规格书下载Download detailed specifications: |
|
| 外形图 The Drawings: |
